Original Enerpac Digital, Hydraulic Pressure Gauges
1>. Digital, Hydraulic Pressure Gauges Rated for system pressure up to 1380 bar Displays high pressure in bar, psi, MPa
Basic Info.
Model NO. | DGR-2 |
Connection Type | Radial Direction |
Function | Electric Signal-controlled |
Installation Structure | Embedded |
Features of Measurement Medium | Corrosion Resistant |
Indicating Pressure Reference | Absolute Pressure Gauge |
Standard | Standard |
Power | Hydraulic |
Double-Acting Cylinder Type | Common Cylinder |
Pressure Direction | Single-Acting Cylinder |
Material | Stainless Steel |
Usage | Automation and Control |
Brand | Enerpac |
Transport Package | CTN |
Specification | steel |
Trademark | ENERPAC |
Origin | USA, China |
HS Code | 8412210000 |
Production Capacity | 100, 000PCS/Year |
Product Description
1>. Digital, Hydraulic Pressure Gauges
Rated for system pressure up to 1380 bar
Displays high pressure in bar, psi, MPa and kg/cm2
Zero reset - ensures that gauge reads actual pressure
IP65 protection
3 Volt battery included (type CR2430), condition indicator on read-out
Shut-off slectable - menu driven
Protective cover included.
Pressure Rating (bar) | Model Number | Pressure Rating (MPa) | Pressure Rating (Kg/cm2) | Weight (kg) | |||
Range | Interval | Range | Interval | Range | Interval | ||
0 - 1380 | 0,1 | DGR-2 | 0 - 140 | 0,01 | 0 - 1400 | 0,1 | 0,23 |
2>.G, H-Series, Hydraulic Pressure Gauges
Glycerine Filled Hydraulic Pressure Gauges (G-Series)
Dual scale reading calibrated in bar and psi
All pressure sensing parts sealed and dampened by glycerine for long life
Includes safety blow-out disk and pressure equalizing membrane
Gauge snubbers or needle valves recommended for high cycle applications.
High Cycle Dry Hydraulic Pressure Gauges (H-Series)
Dual scale reading calibrated in bar and psi
Ideal for use in many applications, specifically for high cycle and harsh environments
Gauge snubbers or needle valves recommended to shut off gauge when not in use.
Pressure Range | G-Series Model Number Glycerine Filled Gauges | H-Series Model Number Dry Gauges | |||||
ø 63 1/4" NPTF Lower Mount Accuracy: ± 1.5 % | ø 63 1/4" NPTF Center Rear Accuracy: ± 1.5 % | ø 100 1/4" NPTF Lower Mount Accuracy: ± 1.0 % | ø 100 1/2" NPTF Lower Mount Accuracy: ± 1.0 % | ø 100 1/4" NPTF Lower Mount Accuracy: ± 1.0 % | ø 100 1/2" NPTF Lower Mount Accuracy: ± 1.0 % | ||
psi | bar | ||||||
0-100 | 0-7 | G2509L | - | - | - | - | - |
0-160 | 0-11 | G2510L | - | - | - | - | - |
0-200 | 0-14 | G2511L | - | - | - | - | - |
0-300 | 0-20 | G2512L | - | - | - | - | - |
0-600 | 0-40 | G2513L | - | - | - | - | - |
0-1.000 | 0-70 | G2514L | G2531R | - | - | - | - |
0-2.000 | 0-140 | G2515L | - | - | - | - | - |
0-3.000 | 0-200 | G2516L | - | - | - | - | - |
0-6.000 | 0-400 | G2517L | G2534R | - | - | - | - |
0-10.000 | 0-700 | G2535L | G2537R | G4088L | G4039L | - | - |
0-15.000 | 0-1000 | G2536L | G2538R | G4089L | G4040L | - | - |
0-10.000 | 0-700 | - | - | - | - | H4049L | H4071L |
3>.GF, GP-Series, Hydraulic Force & Pressure Gauges
Enerpac GF-Series hydraulic force and pressure gauges are calibrated with dual scale reading for pressure and force in bar and kN
GF-series gauges: all pressure sensing parts are sealed and dampened by glycerine for long life
GP-series gauges: calibrated with dual scale reading for pressure in bar and psi
Excellent readability: gauge face dimensions 100 mm
Fast, easy installation
Stainless steel gauge cases for corrosion resistance.
For use with cylinders | Gauge Calibration | Units per division | Model Number | Thread | Required Gauge Adaptor Model Nr. | ||||||
psi | bar | kN | bar | kN | psi | NPTF | |||||
all | 0 - 10.000 | 0 - 700 | - | 10 | - | 100 | GP-10S | 1/2" | GA-2 | ||
all | 0 - 15.000 | 0 - 1000 | - | 10 | - | 200 | GP-15S | 1/2" | GA-2 | ||
5 ton | - | 0 - 700 | 0 -45 | 10 | 0,5 | - | GF-5B | 1/2" | GA-2 | ||
10 ton | - | 0 - 700 | 0 - 100 | 10 | 1 | - | GF-10B | 1/2" | GA-2 | ||
25 ton | - | 0 - 700 | 0 - 232 | 10 | 2 | - | GF-20B | 1/2" | GA-2 | ||
RC, RR 50 ton | - | 0 - 700 | 0 - 500 | 10 | 5 | - | GF-50B | 1/2" | GA-2 | ||
RCH 13 ton | - | 0 - 700 | 0 - 124 | 10 | 1 | - | GF-120B | 1/2" | GA-2 | ||
RCS-201, 302 | - | 0 - 700 | 0 - 175 / 275 | 10 | 2 + 5 | - | GF-230B | 1/2" | GA-2 | ||
RCS-502, 1002 | - | 0 - 700 | 0 - 450 / 900 | 10 | 5 + 10 | - | GF-510B | 1/2" | GA-2 | ||
RCH-202, 302, 603 | - | 0 - 700 | 0 - 210 / 320 / 570 | 10 | 5 | - | GF-813B | 1/4" | GA-3 | ||
25, 30, 50 ton | - | 0 - 700 | 0 - 232 / 300 / 500 | 10 | 5 | - | GF-835B | 1/4" | GA-3 | ||
75, 100 ton | - | 0 - 700 | 0 - 720 / 930 | 10 | 10 | - | GF-871B | 1/4" | GA-3 | ||
150, 200 ton | - | 0 - 700 | 0 - 1400 / 2000 | 10 | 25 | - | GF-200B | 1/4" | GA-3 |
4>. T-Series, Test System Gauges
Enerpac test system gauges are calibrated for dual scale reading in psi and bar
All test gauges have spring-loaded backs with rubber blow-out plugs to protect case assembly in case of over-pressurization
Integral maximum indicator pointer standard included
2800 and 3500 bar models include flange mounting
½" NPTF versions are made of high strength alloy steel
0.25" cone models are made of 316 stainless steel, with 403 stainless steel on 2800 and 3500 bar models.
Pressure Range | Model Number | Accuracy | Number of Intervals bar | Graduation of Intervals bar | Number of Intervals psi | Graduation of Intervals psi | ||
Alloy Steel 1/2" NPTF | Stainless Steel 0,25" Cone | |||||||
bar | psi | |||||||
0-70 | 0-1000 | T-6001L | - | ± 0,5 % | 10 | 1 | 100 | 10 |
0-350 | 0-5000 | T-6002L | - | ± 0,5 % | 50 | 5 | 500 | 50 |
0-700 | 0-10.000 | T-6003L | T-6007L | ± 0,5 % | 100 | 10 | 1000 | 100 |
0-1400 | 0-20.000 | - | T-6008L | ± 0,5 % | 200 | 20 | 1000 | 100 |
0-2800 | 0-40.000 | - | T-6010L | ± 1,5 % | 500 | 20 | 5000 | 200 |
0-3500 | 0-50.000 | - | T-6011L | ± 1,5 % | 500 | 50 | 5000 | 200 |
